| Part No. | FAC-SCA-OS2 |
| Product ID | 020306001 |
| MOQ | 1 Piece |
| Lead Time | 5-7 Working Days according to Quantity |
Product Highlights
Factory pre-polished completely eliminate the need for hand polishing in the field
Mechanical splice technology ensuring precision fiber alignment
Immediate low loss termination
Available in SC, LC, or FC variants
Used in buildings and floors for LAN & CCTV applications
See More
Description
The SC/APC fast connector are factory pre-polished, field-installable connectors that completely eliminate the need for hand polishing in the field. Proven mechanical splice technology ensuring precision fiber alignment, a factory pre-cleaved fiber stub and a proprietary index-matching gel combine to offer an immediate low loss termination to either single-mode or multimode optical fibers.
The Field Assembly Connector series are already a popular solution for optical wiring inside buildings and floors for LAN & CCTV applications and with the expansion of FTTH, is already proving itself to be the connector of choice by incumbents, municipalities, utilities & alternative carriers. Our Field Assembly Optical Connector series are now available in SC, LC, or FC variants, catering for 250um to 900um, and 2.0mm, 3.0mm diameter single mode and multimode fiber types, including Multi-mode 62.5/125um and Multi-mode 50/125um. The single-mode versions are available with SPC or APC ferrules.
Please kindly note that 0.9mm, 2.0mm and 3.0mm diameter are for the same usage. If 2.0mm or 3.0mm are needed, just remove the tail handle from 0.9mm fast connector.
Specifications
| Connector Type | SC | Polishing | APC |
| Ferrule | Ceramic | Fiber Mode | 9/125μm Singlemode |
| Cable Diameters | 0.9/2.0/3.0mm | Dimension | 50mm |
| Insertion Loss | ≤0.35dB | Return Loss | ≥50dB |
| Tension Test | 900µm 10N, 2.0mm 20N, 3.0mm 50N | Temperature | Storage -40 to 85°C Operating -40 to 85°C |
Features
Pre-polished Connectors Support Installating in the Field
Reinserted up to Two Times
For Singlemode Optic Cables
Insertion Loss ≤0.35dB
Installation Instruction
